140 Motor Grader LVR

Overview

The Cat^® 140 Motor Grader combines technology and lever controls for high performance. Integrated technology, such as Cat Grade with Cross Slope and Stable Blade options, ensures optimal grade for your project. The new cab offers increased comfort and ergonomically designed, adjustable control console. Reduce up to 10 percent fuel consumption by using Eco Mode and 20 percent in fluid and filter maintenance costs with the new filtration technology.

Key Features

More Comfort. More Performance. More Versatility.

Lower maintenance costs

Extend typical maintenance intervals with the new filtration technology and grouped filters for easy access.

Cab Designed for comfort

Be productive and comfortable with steering wheel and lever controls and the ergonomically adjustable console and seat.

Material savings

Use less material with scalable Cat Grade technology solutions to increase accuracy and consistency.

Media Gallery

Specifications

Net Power - EEC 80/1269	250 hp
Net Power - ISO 9249/SAE J1349	250 hp
Standard Capability	109 °F
Engine RPM	2,000
Engine Model	Cat C9.3
Bore	4.5 in
Emissions	U.S. EPA Tier 4 Final/EU Stage V
Displacement	567.5 in³
Stroke	5.9 in
Number of Cylinders	6
Torque Rise - ISO 9294	44%

Operating Weight - Typically Equipped	44613 lb

Blade Width	12 ft
Cutting Edge	6 in
Arc Radius	16.3 in
Throat Clearance	6.5 in
End Bit	6 in

Air Conditioning	The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a or R1234yf. See the label or instruction manual for identification of the gas.
