The Cat® CB7 Asphalt Compactor offers enhancements that simplify operation, provide versatility, and deliver excellent fuel economy. Rotary dials, oscillatory vibration, and 360º seating make this compactor a perfect match for urban streets, highways, and other intermediate-type applications.
with standard Eco-mode and automatic idle shutdown.
with easy-to-use dial indicators, application profiles, and a touchscreen display.
with Compaction Control Technologies, flexible vibratory systems, and a reliable water spray system.
| Operating Weight - With Cab | 19588 lb |
|---|---|
| Maximum Operating Weight with Cab | 20404 lb |
| Standard Operating Weight with ROPS | 19015 lb |
| Maximum Operating Weight with ROPS | 19834 lb |
| Standard Compaction Width | 59 in |
|---|---|
| Maximum Compaction Width | 65 in |
| Static Linear Load - With Cab | 172 lb/in |
| Static Linear Load - With ROPS/FOPS | 168 lb/in |
| Travel Speed - Maximum | 7 mile/h |
| Overall Length | 179 in |
|---|---|
| Overall Width | 78 in |
| Height - With ROPS/FOPS or Cab | 118 in |
| Wheel Base | 130 in |
| Drum Diameter | 44 in |
| Engine Model | Cat® C3.6 |
|---|---|
| Engine Power (1) | 100 hp |
| Drum Width | 59 in |
|---|---|
| Centrifugal Force per Drum - Maximum | 17602 lb |
| Centrifugal Force per Drum - Minimum | 11982 lb |
| Nominal Amplitude - High | 0.026 in |
| Nominal Amplitude - Low | 0.012 in |
| Vibration Selection | Independent per drum, front only, rear only, both |
| Fuel Tank Capacity | 36 gal (US) |
|---|---|
| Water Spray Tank Capacity | 195 gal (US) |
