The AP555 Mobil-trac™ asphalt paver is sized right for both urban and rural applications. It delivers excellent traction and mobility as-well-as easy set-up, and a wide paving range making it the perfect fit for urban streets, parking lots, rural roads and many other small to intermediate-type applications.
More performance is delivered with increased feeder system capability, more power, and hopper insert capability
The dual sliding stations, easy-viewing display, and unobstructed visibility to the hopper combine to simplify operation.
Configurable screed designs, optimized weight and width, and the mobil-trac undercarriage design provides contractors with excellent flexibiity.
| Paving Range with SE47 FM | 2.4 m - 6.1 m (8' - 20') |
|---|---|
| Paving Range with SE47 V | 2.4 m - 6.2 m (8' - 20' 6") |
| Truck Entry Height | 22 in |
| Operating Length | 19.25 ft |
| Operating Width | 10.75 ft |
| Overall Height | 10.75 ft |
| Transport Length | 18.5 ft |
| Transport Width | 8.5 ft |
| Transport Height | 9.3 ft |
| Engine Power (1) | 148 hp |
|---|---|
| Engine Model (1) | Cat C4.4 |
| Maximum Paving Speed | 200 ft/min |
|---|---|
| Maximum Travel Speed | 7 mile/h |
| Maximum Throughput Capacity | 1100 ton(US)/h |
| Operating weight with SE47 FM | 33689 lb |
|---|---|
| Operating weight with SE47 V | 33448 lb |
| Shipping Weight - Paver Only | 26993 lb |
| Fuel Tank | 53 gal (US) |
|---|---|
| DEF Tank | 5 gal (US) |
| Cooling System - Total | 6.3 gal (US) |
| Hydraulic Oil Tank | 32 gal (US) |
| Washdown Spray Tank | 8.5 gal (US) |
